Transistor series

Photocoupler series

The main function of the PS2500 series is very high between the input and output isolation voltage. To improve the optical dielectric strength of the PS2500 series dual-molding package structure has been completed. High isolation voltage, the PS2500 series of photoelectric boast high heat and high humidity, and resistance.

Target applications

Power supply
Phone / Fax
Split Air Conditioner
The FA / OA equipment
Programmable logic controller

Switching diode series

The switching diode is designed for high-speed switching applications. Dual diode device includes two diodes in series is packaged in the SOT-23 surface mount package.

Transistor series

This NPN bipolar transistor is designed for general VHF / UHF applications, are housed in SOT-23 surface mount package. This device is ideal for low power surface mount applications.

Differential bus transceiver series

The SN65176B and SN75176B differential bus transceiver IC designed for bidirectional data communication on multipoint bus transmission lines. They are designed for balanced transmission lines, and in accordance with the ANSI standard TIA/EIA-422-B and TIA/EIA-485-A and ITU V.11 and X.27 recommendations.

SN65176B, and SN75176B three-state differential line driver and differential input line receiver, from a single 5V supply, the two operations. Driver and receiver high and active-low enable, respectively, can be externally connected together as a direction control function. The driver differential outputs and receiver differential input is connected internally to form differential input / output (I / O) bus port design of the bus when the minimum load driver is disabled or V CC = 0. These ports have a wide range of positive and negative common-mode voltage range, making the device suitable for the party's line applications.

The driver design sink or source current 60 mA. The drive has both positive and negative current limiting and thermal shutdown protection circuit fault conditions. Thermal shutdown occurs in the temperature of about 150 ° C junction receiver has a minimum input impedance of 12 K with an input sensitivity of ± 200 mV typical input hysteresis and 50 mV.

SN65176B, and SN75176B can be used for the transmission line using SN75172 and SN75174 four differential line drivers and SN75173 and SN75175 differential line receiver applications.

Quad op-amp series

These devices include four independent high-gain frequency compensation op amp is designed to operate from a single supply a wide voltage range. Operating from split supplies is also possible, if the difference between the two power supply (3 V 3V to 32V to 26V for LM2902), VCC is positive over at least 1.5 volts of input common-mode voltage. The low supply current consumption is independent of the magnitude of the supply voltage.

Applications include transducer amplifiers, dc amplification blocks, and all the traditional op amp can now be easier to achieve single-supply voltage circuit. For example, the LM124 can directly manipulate the standard 5V power supply, used in digital systems, and provide the necessary interface without the need for additional electronics, ± 15 V power supply.

Transistor series

Key features and benefits

Short storage time
Small and very small package
The VCEO up to 40 V, NPN transistor (-60 PNPtypes)
IC range up to 800 mA
Low saturation voltage

Target applications

Universal switch
Logic level converter
Supply line switch
Battery charging switch

Transistor series

Low-frequency small-signal amplifier with transistors

IC Series

 5V CMOS logic circuit series

The standard positive voltage regulator series

These devices are very reliable and stable performance, suitable for general consumer electronics, switching power supplies and industrial applications. The cream of the input; voltage is 40 V, maximum current one. ; Output voltage differential is divided into fixed and adjustable two types, a minimum of 1.2V, the typical dropout voltage of 1.1 to 1.7V.

The type of device package (low power to high power), including the SOT-89, TO-92, SO-8 DPAK-available in a D2PAK package, 220,220 the FP, Pentawatt and 3.

Transistor series

Target applications

Pay DC merchant power supply - video game consoles, flat-panel TVs, video recorders, set-top boxes
